Dual Screen Touch Screen Self Service Kiosk with Capacitive Touchscreen and Customizable Size
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | Shareme |
| Certification: | CE，ROHS |
| Model Number: | SHM-TSCM15 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | 400$ |
| Packaging Details: | Cardboard boxes |
| Delivery Time: | 5-8 days |
| Payment Terms: | T/T,Western Union |
| Supply Ability: | 10000 |
|
Detail Information |
|||
| Barcode Scanner: | Optional | Brightness: | 400cd/m2 |
|---|---|---|---|
| CPU: | Intel/AMD | Camera: | Optional |
| Card Reader: | Optional | Memory: | 4GB/8GB/16GB |
| Network: | Wi-Fi/Ethernet/3G/4G | Operating System: | Windows/Android/Linux |
| Printer: | Optional | Resolution: | 1920x1080 |
| Size: | Customized | Speaker: | Optional |
| Storage: | 128GB/256GB/512GB | Touchscreen: | Capacitive |
| Highlight: | Desktop Touch Screen Ordering Kiosk,Self Service Touch Screen Ordering Kiosk |
||
Product Description
Desktop Self-Service Touch Screen Ordering Kiosk
Advanced dual-screen self-service cashier and check-in machine featuring IC card reader, QR code scanner, POS integration, and thermal printer. Designed for flexible installation with stand, wall-mount, or desktop placement options.
Key Features
- Dual touch screen displays for operator and customer interaction
- 10-point PCAP touch or capacitive film touch technology
- Integrated QR code scanner and thermal receipt printer
- Multiple operating system support: Windows 7/10/11 or Android 7.1/9.0/11
- Flexible installation: desktop stand, wall-mount, or counter placement
- Available from stock with customization options
Technical Specifications
| Component | Android Configuration | Windows Configuration |
|---|---|---|
| Main Board & CPU | RK3288: Quad core 1.8GHz RK3568: Quad-core Cortex-A55 up to 2.0GHz |
J1900: Quad core 2.0GHz J4125: Quad core 2.0GHz J6412: Quad core 2.0GHz (Supports Core i3/i5/i7 CPU) |
| Operating System | RK3288: Android 9.0 RK3568: Android 11 |
Windows 7/10/11, Linux |
| Display | 15.6" LED TFT portrait 250 nits brightness 1366×768 (1920×1080P optional) |
15.6" LED TFT portrait 250 nits brightness 1366×768 (1920×1080P optional) |
| Touch Screen | Capacitive touch screen 35-90° tilting angle |
Capacitive touch screen 35-90° tilting angle |
| RAM & Storage | 2GB RAM 16GB SSD |
4GB/8GB RAM mSATA 64GB/128GB/256GB SSD 1× mSATA Slot |
| I/O Ports | 1× COM 5× USB 2.0 (External) 2× USB 2.0 (Internal) 1× RJ-45 Giga LAN 1× RJ11 1× +12V 5A DC Audio: Line Out, MIC In, Internal Speaker WiFi: IEEE802.11b/g 1× SIM card slot 1× TF card slot |
1× COM 5× USB 2.0 (External) 2× USB 2.0 (Internal) 1× RJ-45 Giga LAN 1× VGA (DB-15 Female) 1× +12V 5A DC Audio: Line Out, MIC In, Internal Speaker WiFi (optional) |
| Peripherals | 80mm thermal receipt printer 1D+2D barcode scanner 15.6" customer display with touch |
80mm thermal receipt printer 1D+2D barcode scanner 15.6" customer display with touch |
| Optional Features | MSR, Speaker, RFID (read/read+write) | MSR, WiFi, Speaker, RFID (read/read+write) |
Printer Specifications
80mm thermal receipt printer with printing speed of 150mm/s, work life of 100km, cutter life of 1,000,000 cycles, and supports paper rolls up to 80mm diameter.
Complete POS Solutions
Shareme provides comprehensive point-of-sale solutions including cash registers, touch screens, cash drawers, POS printers, barcode/label printers, portable printers, dot matrix printers, kitchen receipt printers, barcode scanners, customer display screens, and magnetic card readers.
Our systems support complete business management functions including purchasing and invoicing, inventory control, sales analysis, and price setting through intuitive Windows or Android platforms.
Shareme maintains an in-house design and support team to provide customers with uninterrupted service and technical assistance.
Want to Know more details about this product
