24 Inch Capacitive and Infrared Touch Screen Monitor Interactive Touch Panel All-In-One Touch Computer
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | Shareme |
| Certification: | CE，ROHS |
| Model Number: | SHM-BGGK24 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | 500$ |
| Packaging Details: | Cardboard boxes |
| Delivery Time: | 5-8 days |
| Payment Terms: | T/T,Western Union |
| Supply Ability: | 10000 |
|
Detail Information |
|||
| Aspect Ratio: | 16:9 | Brightness: | 250 Cd/m2 |
|---|---|---|---|
| Contrast Ratio: | 1000:1 | Display Size: | 15-27 Inch |
| Display Type: | LCD | Inputs: | HDMI, VGA, DVI |
| Power Consumption: | 30W | Resolution: | 1920 X 1080 |
| Response Time: | 5ms | Speakers: | 2 X 2W |
| Touch Interface: | USB | Touch Points: | 10 Points |
| Touch Screen Type: | Infrared,capacitive | VESA Mount: | Yes |
| Viewing Angle: | 178°/178° | ||
| Highlight: | Capacitive Touch Screen Monitor Panel,24 Inch Touch Screen Monitor Panel,Interactive Hp 24 Inch Touch Screen |
||
Product Description
24-Inch Capacitive Touch Screen Monitor Panel
Interactive All-in-One IR Computer with advanced industrial-grade construction and performance features.
Key Features
- Aluminum alloy shell with excellent mechanical properties and superior heat dissipation
- Compatible with various industrial systems and applications
- Standard VGA + HDMI with automatic signal channel identification
- Anti-jamming design meeting EMI standards
- Triple protection: explosion-proof, flameproof, and moisture-proof
- Shock resistance compliant with GB2423 standards for transportation and marine operations
- Anti-static protection: contact 4KV (customizable up to 8KV), air 8KV (customizable up to 16KV)
- Anti-surge design ensuring proper function during instantaneous voltage spikes up to 280V
Technical Specifications
General Specifications
| Series | Open Frame, IP65 Water-proof & Vandal Proof |
| LCD Type | 24" Active matrix TFT-LCD |
| Video Input | VGA and DVI |
| OSD Controls | Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset |
| Power Supply | External brick | Input: 100-240 VAC, 50-60 Hz | Output: 12V at 4A max |
| Mount Interface | VESA 75mm and 100mm | Horizontal or vertical kiosk mounting |
LCD Specifications
| Active Area | 522.32mm (H) × 294.36mm (V) |
| Resolution | 1920 × 1080 @ 60Hz |
| Dot Pitch | 0.264mm (H) × 0.264mm (V) |
| Viewing Angle | 85°/85°/88°/88° (CR>10) |
| Contrast Ratio | 1000:1 |
| Luminance | 250 cd/m² |
| Response Time | 5ms/10ms |
| Support Color | 16.2M colors |
| Backlight MTBF | 30,000 hours |
Touchscreen Specifications
| Type | Shareme Touch Projected Capacitive with 3mm Vandal Proof Glass |
| Multi Touch | 10 points touch |
| Touch Life Cycle | 50 million touches |
| Touch Response Time | 8ms |
| Interface | USB |
| Power Consumption | +5V @ 80mA |
Quality Assurance & Services
Shareme Touch maintains ISO 9001 certification and holds CE, UL, FCC, RoHS international certifications.
Product Offerings
- Single & Multi-touch screens (custom sizes available)
- Single & Multi-touch monitors (custom sizes and functions available)
- All-in-one computers
- ODM/OEM services
Advanced Technologies
Continuous innovation in touch technology including Surface Acoustic Wave (SAW), Infrared touch, and Projected Capacitive touch technologies.
